Quick Features
| Name of Commodity | Storage Water Heaters |
| LED Indicator | To indicate the real time hotness of the water. |
| Mounting | Vertical |
| Star Rating as per BEE Standard | 5 star |
| Warranty | 5 year + 2 year extended warranty on inner container ; 2 year comprehensive warranty & 3 year warranty on heating element |
Detail Features
| Viterous Enamel Inner Container | A. Made of Ultra thick super cold rolled steel plates B. Provides more corrosion resistance and anti rust property resulting in longer life compared to standard inner tank designs. C. A die hard life span for inner tank and more than 25% strength than S.S. tank, ensured by multiple on line testing including 1. Uric Acid Test 2. Anti Alkaline Test 3. Fatigue Test 4. Environment Synchronization Test |
| Incoloy Heating Element | Incoloy 800 glass coated Heating element offers superior heating performance resistance to both oxidation & carbonization at high temp. setting. Also resists errosion against most extreme and hard water conditions thus extending life span of heating elements with minimum energy loss. |
| Energy Saving High Density PUF Insulations | CFC free thicker PUF insulation offers complete protection against radiant heat loss. |
| Shock Safe plug | Shock safe plug designed to prevent electric shocks by cutting off the power in case of current leakage. |
| Whirlflow Technology | It avoids direct contact between cold and hot water flow for a faster heating and optimized energy saving effecting 20 % more hot water outputs. |
| 8 Bar Pressure | uitable for high rise buildings and pressure pump applications. The multi function valve prevents pressure to increase beyond 8 bar. |
| Adjustable Knob | Adjustment knob for setting the temperature conveniently. |
| LED Indicator | To indicate the real time hotness of the water. |
| Warranty | 5 years + 2 years extended warranty for inner container , 3 years warranty on heating element and 2 years comprehensive warranty. |
Technical SpecificationBASIC FEATURES
| Rated capacity | 15 L |
| Installation | Vertical |
| Color | White Blue |
| Ideal for | Bathroom , High rise buildings |
| Heating Indicator | Yes |
| Temperature Setting | Manual |
| Whirl flow technology | Yes |
PERFORMANCE FEATURES
| Rated Pressure | 0.8 MPa |
| Standing loss in kWh 24 hours 45 °C | 0.419 kWh |
| Reheating time in minutes to raise 50 °C | 24 minutes |
| Mixing factor maximum | 30 % |
| External tempertaure indicator | No |
POWER DETAILS
| Rated power input | 2000 W |
| Rated Voltage & frequency | 230 V, 1 Ph, 50 Hz AC |
| Rated Input Current | 8.7 A |
| BEE Rating | 5 Star |
| Energy Efficiency feature | Energy saving high density PUF insulation |
DIMENSIONS WEIGHT
| Weight when empty | 10.5 kg |
| Height | 395 mm |
| Width | 395 mm |
| Breadth | 344.5 mm |
| Packing dimensions LxWxH (cm) | 45.5 cm x 44.5 cm x 40.5 cm |
TANK FEATURES
| Tank Material | Made of ultra thick super cold rolled steel plates |
| Tank finish and coating | Viterous enamel inner container |
| Heating element | Incoloy 800 glass coated heating element offers superior heating performance and resistance to oxidation and carbonation at high temperatures |
| Extreme hard water resistance | Yes |
| Anode Rod (rust and corrosion resistance) | Heavy duty magnesioum anode rod woth steel core to protect enamelled tank from rust and corrosion |
SAFETY FEATURES
| Multifunctional safety valve | Yes |
| Geyser protection from water splash | IPX4 technology to protect electrical parts from water splash |
| Thermostat | Yes |
| Thermal cut off | Yes |
| Electrical safety | Shock safe plug |
SALES PACKAGE (S)
| Net contents | 1 N storage electric water heater , 1 N user manual , 1 N multi-function safety valve, 1 N mounting bracket , 2 N fasteners & 2 N flexi pipes |
WARRANTY \ GUARANTEE
| Tank Warranty | 5 Year + 2 Year extended |
| Body and electrical components Warranty | 2 Year |
| Heating Warranty | 3 Year |
