Quick Features
| Name of Commodity | Storage Water Heaters |
| Range Available | 25 L |
| Mountin | Vertical |
| Star Rating as per BEE Standard | 4 Star |
| Warranty | 7 year warranty on inner container ; 2 year comprehensive warranty ; 4 year heating element warranty |
Detail Features
| Dry Powder Feroglas Coated Inner Container | A. Made of Ultra thick super cold rolled steel plates B. Provides more corrosion resistance and anti rust Property resulting in longer life compared to standard inner tank designs. C. A die hard life span for inner tank and more than 25% strength than S.S. tank, ensured by multiple on line testing including 1. Uric Acid Test 2. Anti Alkaline Test 3. Fatigue Test 4. Environment Synchronization Test |
| Incoloy Heating Element | Incoloy 800 glass coated Heating element offers superior heating performance resistance to both oxidation & carbonization at high temp. setting. Also resists errosion against most extreme and hard water conditions thus extending life span of heating elements with minimum energy loss. |
| Energy Saving High Density PUF Insulations | CFC free thicker PUF insulation offers complete protection against radiant heat loss |
| Color changing ring LED Indicators | |
| Safety | India’s 1st intergerated shock safe plug |
| Other Star Features | Water tubes with whirl flow technology Heating indicator lamp |
Technical SpecificationBASIC FEATURES
| Rated capacity | 25 L |
| Installation | Vertical |
| Color | White Blue |
| Color Options | White Mustard |
| Ideal for | Bathroom , High rise buildings |
| Color Changing Ring LED Indicators | Yes |
PERFORMANCE FEATURES
| Whirl Flow Technology | Yes |
| Rated Pressure | 0.8 MPa |
| Standing loss in kWh 24 hours 45 °C | 0.562 kWh |
| reheating time in minutes to raise 50 °C | 41 minutes |
| Mixing factor maximum | 30 % |
| External tempertaure ring LED indicator | Yes |
POWER DETAILS
| Rated power input | 2000 W |
| Rated Voltage | 230 V, 1 Ph, 50 Hz AC |
| Rated Input Current | 8.7 Ampere |
| BEE Rating | 4 Star |
| Energy Efficiency feature | Energy saving high density PUF insulation |
DIMENSIONS WEIGHT
| Weight when empty | 11.6 kg |
| Height | 606 mm |
| Width | 380 mm |
| Breadth | 340 mm |
| Packing dimensions LxWxH (cm) | 66.5 cm x 43.5 cm x 39.2 cm |
TANK FEATURES
| Tank Material | Made of ultra thick super cold rolled steel plates |
| Tank finish and coating | Feroglas dry powder coating technology |
| Heating element | Incoloy 800 glass coated heating element offers superior heating performance and resistance to oxidation and carbonation at high temperatures |
| Extreme hard water resistance | Yes |
| Anode Rod (rust and corrosion resistance) | Heavy duty magnesioum anode rod with steel core to protect enamelled tank from rust and corrosion |
SAFETY FEATURES
| Multifunctional safety valve | Yes |
| Geyser protection from water splash | No |
| Thermostat | Yes |
| Thermal cut off | Yes |
WARRANTY \ GUARANTEE
| Tank Warranty | 7 Year |
| Body and electrical components Warranty | 2 Year |
| Heating elemet Warranty | 4 Year |
SALES PACKAGE (S)
| Net contents | 1 N storage electric water heater , 1 N user manual , 1 N multi-function safety valve , 2 N fasteners & 2 N flexi pipes |
