Cable Construction
1.1 kV, 1 cores AL / CU conductor, XLPE insulated, unarmoured cables as per IS 7098 Part – 1.
Conductor : AL up to 10 Sq. mm conductor are solid Cl. 1 as per IS 8130. And above 10 Sq. mm conductor are stranded round or compact Cl.
2 as per IS 8130
In CU 4 & 6 Sq. mm conductor are solid Cl. 1 or stranded Cl. 2 as per IS 8130. 10 Sq. mm & above stranded round or stranded compact
Cl. 2 as per IS 8130
Insulation : Crosslinked polyethylene (XLPE)
Core Color : Red or yellow or blue or black or natural
Outer Sheath : PVC Type ST – 2 as per IS 5831 (Option: FR Type / FRLS Type)
Cable Color : Black (Options: Any other color as per requirement)
