Application
These cables are ideal for use in automotive and marine applications where higher current carrying capacity and mechnical strength are required.
Standard
In accordance with ISO 6722
Specifications
Voltage Rating : 60V DC, 25V AC
(suitable for 12V and 24V systems)
Temperature Range : -40°C to +105°C (3000 hours)
Cable Construction
Soft annealed electrolytic copper Cu-ETP according to DIN EN 13602.
Conductor construction according to ISO 6722.
PVC insulation, Cl. B to ISO 6722.
PVC sheath, Cl. B to ISO 6722.
Packing :Packing available in 100 mtr. Longer length in spools or wooden drums.
Properties
The lead free, PVC polymer, offers excellent resistance to petrol, chemicals and abrasion.
Higher mechanical strength.
The cable is suitable for both, low and high temperature applications.
Flame retardant to EN 60332-1-2.
